Κέντρο κατεργασίας - καθολικό

DMG MORI DMC 340 U

x-axis travel: 3,400 mm
y-axis travel: 3,400 mm
z-axis travel: 1,600 mm
Control: CELOS 840D sl Op Siemens
Max. spindle speed: 20 – 15,000 rpm
Drive power – main spindle: 52 / 42 kW
Tool holder: HSK-A100
Max. torque: 404 / 280 Nm
Swiveling range B: -30° / +180°
Table size: 2,500 x 2,000 mm
Max. table load: 10,000 kg
Table rotation speed: 5 rpm
Distance spindle center to table (horizontal): 130 – 1,730 mm
Distance spindle center to table (vertical): 230 – 1,830 mm
Distance spindle nose to table (horizontal): -1,500 – 1,900 mm
Distance spindle nose to table (vertical): -1,600 – 1,800 mm
Type: 5x Rad- / Wheel
Number of tool pockets: 303 pos.
Max. tool diameter: 110 mm
Max. tool diameter with empty adjacent pocket: 280 mm
Ljdpfxjx H Tt De Afiorn
Max. tool length: 900 mm
Max. tool weight: 45 kg
Tool change time: 7.5 sec
Tool holder: HSK-A100
Rapid traverse: 60 / 30 / 40 m/min
Total power requirement: 140 kVA
Machine weight approx. 106 t
Space requirement approx. 14.0 x 13.0 x 7.0 m
5-axis CNC large machining center universal
DMG MORI - DMC 340 U

- Pallet changer, 2 positions
- Precision package
- MDynamics package
(Improved surface finish with reduced machining time)

- Only approx. 10,500 h spindle hours
- Taper cleaning station with rotating brushes
- Balluff tool identification
- Machine protection via rapid shutdown (MPC)
- Laminated safety glass
- Machine design for installation in pit
- Heidenhain linear scales (instead of Magnescale)
- Camera remote system with screen at control panel
